Extra-X MK4 Value Checks

Use the following measurements to verify good components within your Extra-X Mark 4 before installing a new circuit board. Bad components will cause damage to your new circuit board. If you find a bad component, replace it before installing your new circuit board.


Input Power - 115 volts AC / 60 Hz / 15 amps / 1150 watts

Dryer Temperature - 145 to 155 degrees F

Dryer Element - Yellow Wire to Neutral Wire - 16 ohms
                              Brown Wire to Blue Wire - 32 ohms


Dryer Fan - 24.5 ohms

Drive Motor - Red Wire to Black Wire - 2.4 Kohms
                         Red Wire to Neutral Wire - 1.2 Kohms

Chemistry Heater Element - 100 ohms

Developer Temperature - 77 to 78 degrees F

Fixer Temperature - 82 to 83 degrees F

Chemistry Temperature Sensors - at 77 degrees F - 2.3 Kohms
                                                                 at 78 degrees F - 2.2 Kohms
                                                                 at 82 degrees F - 1.8 Kohms
                                                                 at 83 degrees F - 1.7 Kohms

Water Solenoid Coil - 1.29 Kohms

Chemistry Circulation Pump Motors - 370 ohms

Replenisher Pump Motor - 20 ohms

Dryer Thermistors - Red Wire, (P20) to Red Wire, (P21) -
60 to 80 ohms
                                      Brown Wire, (P14) to White Wire, (P15) - 65 to 85 ohms


Liquid Level Sensors - Screw head with the orange wire to the orange wire in the molex plug - 0 ohms

Screw head with the blue wire to the blue wire in the molex plug - 0 ohms
                                           Screw head with the yellow wire to the yellow wire in the molex plug - 0 ohms
                                           Screw head with the green wire to the green wire in the molex plug - 0 ohms


NOTE: If the Control PCB receives a reading from the Temperature Sensor out of the target range, the CHEMICAL TEMPERATURE LOW LED will flash.



Extra-X cheques MK4 Valor

Use las siguientes medidas para verificar los componentes buenos dentro de su extra-X Marcos 4 antes de instalar un nuevo tablero de circuito. Los componentes de Bad causará daño a su nuevo tablero de circuito. Si usted encuentra un componente defectuoso, sustituirlo antes de instalar el nuevo tablero de circuito.

Potencia de entrada - 115 voltios AC / 60 Hz / 15 amperios / 1150 vatios

Temperatura de la secadora - 145 a 155 grados F

Elemento Secadora - Cable amarillo al hilo neutro - 16 Ohms

                                        Cable marrón al cable azul - 32 Ohms

Ventilador de la secadora – 24.5 Ohms

Motor Drive - Cable rojo al cable Negro – 2.4 K Ohms

                         Cable rojo al hilo neutro – 1.2 K Ohms



Química elemento calefactor - 100 Ohms

La temperatura del revelador - 77 a 78 grados F

Temperatura Fixer - 82 a 83 grados F

Sensores de temperatura Química - 77 grados F – 2.3 K Ohms

                                                           a 78 grados F – 2.2 K Ohms

                                                           a los 82 grados F – 1.8 K Ohms

                                                           a los 83 grados F – 1.7 K Ohms

Agua Bobina - 1.29 K Ohms

Química Motors Bomba de circulación - 370 Ohms

Reforzador de la bomba del motor - 20 Ohms

Termistores secador - Cable rojo, (P20) al cable rojo, (P21) - 60 a 80 Ohms

                                           Cable marrón, (P14) al cable blanco, (P15) - 65 a 85 Ohms



Los sensores de nivel de líquido -

                                        La cabeza del tornillo con el cable naranja conectado a él para el cable naranja del conector molex - 0 Ohms

                                        La cabeza del tornillo con el cable azul se conecta a él con el cable azul en el conector molex - 0 Ohms

                                        La cabeza del tornillo con el cable amarillo conectado al cable amarillo del conector molex - 0 Ohms

                                        La cabeza del tornillo con el cable verde conectado a él para el cable verde en el conector molex - 0 Ohms

NOTA: Si la placa de control recibe una lectura del sensor de temperatura fuera del rango meta, la baja temperatura QUÍMICA parpadeará.
